Honda Civic Type R & CR-V 2.0 Belt Tensioner

Honda Alternator Belt Tensioner with Pulley

Replacement automatic auxiliary belt tensioner with pulley for the Honda CR-V 2.0, Civic Type R EP3 / FN2 and selected Accord and FR-V petrol models listed below. This aftermarket assembly maintains tension on the auxiliary drive belt, also known as the alternator belt or serpentine belt.

The price includes one complete belt tensioner assembly with pulley. Match the engine code, original part number and tensioner layout before ordering.

When Does a Belt Tensioner Need Replacing?

A worn pulley bearing can cause a squeaking, whistling or rough running noise, sometimes noticeable during start-up. A weakened tensioner spring can allow the belt to slip, while a damaged pulley or worn tensioner pivot can affect belt alignment and tracking.

A new pulley alone will not repair a weak tensioner spring or a worn pivot. If the tensioner mechanism is worn as well as the pulley bearing, replacing the complete assembly addresses both areas. Noise alone does not identify the faulty component: the belt, tensioner and other accessory pulleys should be inspected before replacement.

Honda CR-V, Civic Type R EP3 / FN2, Accord and FR-V Applications

Check the chassis/model code and engine code in the compatibility list below. Dates are application guides; confirm compatibility using the original part number and vehicle details.

• Honda CR-V II 2.0 i-VTEC: catalogue range September 2001–March 2007; chassis/model code RD5; engine code K20A4. Check engine-number restrictions before ordering.
• Honda Civic VII Type R 2.0 i-VTEC: 2001–2005; chassis/model code EP3; engine code K20A2.
• Honda Civic VIII Type R 2.0 i-VTEC: catalogue range September 2006–January 2012; chassis/model code FN2; engine code K20Z4.
• Honda Accord VII 2.0: 2003–2008; chassis/model codes CL7 (saloon) and CM1 (Tourer); engine codes K20A6 / K20Z2.
• Honda Accord VII 2.4: 2003–2008; chassis/model codes CL9 (saloon) and CM2 (Tourer); engine code K24A3.
• Honda FR-V 2.0 i-VTEC: UK 2005–2006 models; chassis/model code BE3; engine code K20A9; check later-registered vehicles by engine code and OE reference.

OE Reference Numbers

• 31170-PNA-023
• 31170-PNA-003
• 31170-PNA-013
• 31170-RAA-A01
• 31170-RAA-A02

OE numbers are provided for identification and compatibility checks. This is an aftermarket replacement.

Before Fitting

Check the auxiliary belt for wear, damage and correct length, and inspect the other pulleys for rough bearings or misalignment. Installation should follow the workshop procedure for the specific engine, including the correct belt routing and tightening specifications.
